Model I 0124 I 0424 I 0824 Compression Advanced MPEG4 ASP Signal Format NTSC or PAL (Auto Selected) Video Input Composite 1 BNC Inputs Composite 4 BNC Inputs Composite 8 BNC Inputs Video Output Composite: 1 (1Vp-p, 75 Ohm) Display Resolution 704 x 480, 704 x 240, 352 x 240 (NTSC) / 704 x 576, 704 x 288, 352 x 288 (PAL) Recording Resolution 704 x 480, 704 x 240, 352 x 240 (NTSC) / 704 x 576, 704 x 288, 352 x 288 (PAL) Recording Frame Rate NTSC 352 x 240 : 30FPS 352 x 240 : 120FPS 352 x 240 : 240FPS PAL 352 x 288 : 25FPS 352 x 288 : 100FPS 352 x 288 : 200FPS Audio Input 1 Inputs (RCA Jack) 4 Inputs (RCA Jack) Audio Output 1 Output (RCA Jack) 4 Output (RCA Jack) Ethernet 10 / 100Mbps Ethernet Port 1 (RJ-45) PTZ Control RS-485 / 422 Serial Port 1 (Terminal Block) ATM / POS RS-232 Serial Port 1 (Terminal Block) Alarm Input 1 (TTL) Programmable as NC / NO 4 (TTL) Programmable as NC / NO 8 (TTL) Programmable as NC / NO Alarm Output 1 (TTL) Programmable as NC / NO Recording Qualities Super / High / Standard Recording Modes Schedule / Alarm / Motion / Emergency Motion Detection Yes (22 X 15) NTP Server Yes GMT Time Zone Yes Auto DST Yes Multi Language English / Danish / Chinese (Traditional) / Japanese / Korean / Italian / Polish / Russian / Chinese (Simplified) / Thai / Turkish / Spanish / French / Czech / German Operating System Embedded Linux OS Firmware Linux OS in Flash Memory Dimension(WxHxD) mm 187 mm x 58 mm x 130 mm inch 7.35 inch x 2.28 inch x 5.12 inch Operating Temperature 5`C~40`C / 41`F~104`F Operating Humidity 0% ~ 90% Power Adapter Free Voltage 12VDC, 5A Power Consumption Max 11W
