| Model |
S 0412 |
S 0824 |
S 1648 |
| Compression |
H.264 (Main
Profile) |
| Signal
Format |
NTSC or
PAL (Auto Selected) |
| Video
Input |
Composite
4 BNC Inputs |
Composite
8 BNC Inputs |
Composite
16 BNC Inputs |
| Video
Output |
Composite:
1 (1Vp-p, 75 Ohm) |
| Loop
Output |
4 BNC Looping Outputs |
8 BNC Looping Outputs |
16 BNC Looping Outputs |
| Spot
Output |
3 BNC |
| VGA
Output |
1 VGA |
| Max
Recording Rate at CIF (FPS) |
120 (NTSC) / 100 (PAL) |
240 (NTSC) / 200 (PAL) |
480 (NTSC) / 400 (PAL) |
| Max
Recording Rate at H.D1 (FPS) |
120 (NTSC) / 100 (PAL)* |
120 (NTSC) / 100 (PAL) |
240 (NTSC) / 200 (PAL) |
| MAx
Recording Rate at Full D1 (FPS) |
60 (NTSC) / 50 (PAL) |
60 (NTSC) / 50 (PAL) |
120 (NTSC) / 100 (PAL) |
| Dual
Stream |
Dual |
| Audio
Input |
4 Inputs (RCA Jack) |
8 Inputs (RCA Jack) |
16 Inputs (RCA Jack) |
| Audio
Output |
1 Output
(RCA Jack) |
| Ethernet |
10 / 100Mbps
Ethernet (RJ-45) |
| PTZ
Control |
RS-485/422
Serial Port 1 (Terminal Block) |
| ATM
/ POS |
Up to 4
Channels Over USB |
| Alarm
Input |
4 (TTL) Programmable
as NC/NO |
8 (TTL) Programmable
as NC/NO |
16 (TTL) Programmable
as NC/NO |
| Alarm
Output |
4 (TTL) Programmable
as NC/NO |
8 (TTL) Programmable
as NC/NO |
16 (TTL) Programmable
as NC/NO |
| USB
Port |
4 x USB
(2 x Front Panel, 2 x Rear Panel) |
| Recording
Qualities |
Super /
High / Standard |
| Recording
Modes |
Schedule
/ Alarm / Motion / Emergency |
| Pre-Alarm
Recording |
up to 3
Hours / User Programmable |
| Motion
Detection |
Yes (22
X 15) |
| Playback
Speed |
X1, X2,
X4, X8, X16, X32, X64, Extreme |
| Archive
File Format |
EXE (Video
Clip) / JPEG (Still Image) |
| NTP
Server |
Yes |
| GMT
Time Zone |
Yes |
| Auto
DST |
Yes |
| Multi
Language |
English
/ Danish / Chinese (Traditional) /
Japanese / Korean / Italian / Polish
/ Russian / Chinese (Simplified) /
Thai / Turkish / Spanish / French
/ Czeko / German / Persian |
| Operating
System |
Embedded
Linux |
| OS
Firmware |
Linux OS
in Flash Memory |
| Emergency
Recording Key |
Yes |
| Primary
Storage |
SATA Hard
Disk Drive (up to 3+1 or 4+0) |
| Clip
Copy Storage |
Built-in
Internal DVD-RW Driver, Via USB HDD,
Memory Stick |
| Dimension(WxHxD) |
430 mm
x 88 mm x 380 mm / 16.93 inch x 3.46
inch x 14.96 inch |
| Operating
Temperature |
5`C~40`C
/ 41`F~104`F |
| Operating
Humidity |
0% ~ 90% |
| Power
Adapter |
Free Voltage
12VDC, 5A |
| Power
Consumption |
Max 37W |
| Agency
Approval |
FCC / CE |
