| Model |
E 0412 |
E 0824 |
E 1648 |
| Compression |
Advanced
MPEG4 ASP / Pentaplex |
| Operating
System |
Embedded
Linux |
| OS
Firmware |
Linux OS
in Flash Memory |
| NTSC
/ PAL Selectable |
Yes |
| Video
Input |
Composite
4 BNC Inputs |
Composite
8 BNC Inputs |
Composite
16 BNC Inputs |
| Video
Output |
Composite:
1 (1Vp-p, 75 Ohm) |
| Monitor
Output |
1 VGA |
| Sequence |
Yes |
| Max
Recording Rate at CIF (FPS) |
120 (NTSC) / 100 (PAL) |
240 (NTSC) / 200 (PAL) |
480 (NTSC) / 400 (PAL) |
| Max
Recording Rate at H.D1 (FPS) |
120 (NTSC) / 100 (PAL) |
120 (NTSC) / 100 (PAL) |
240 (NTSC) / 200 (PAL) |
| MAx
Recording Rate at Full D1 (FPS) |
60 (NTSC) / 50 (PAL) |
60 (NTSC) / 50 (PAL) |
120 (NTSC) / 100 (PAL) |
| Audio
Input |
1 Input (RCA) |
| Audio
Output |
1 Output
(RCA) |
| Ethernet |
10 / 100Mbps
Ethernet (RJ-45) |
| Network Bandwidth Control |
56 kbps ~ Unlimited |
| Video Stream |
Dual |
Selectable* |
| Alarm
Input |
4 (TTL) Programmable
as NC/NO |
| Alarm
Output |
4 (TTL) Programmable
as NC/NO |
| USB Interface |
4 x USB2.0
(2 x Front Panel, 2 x Rear Panel) |
| Search (Date/Time, Calendar, Event) |
Yes |
| User Interface (GUI / Control Device) |
Yes / Keypad, Mouse, PTZ Control, Remote Controller |
| External Storage |
None |
| Archive File Format |
EXE (Video Clip) / JPEG (Still Image) |
| NTP Server |
Yes |
| GMT Time Zone |
Yes |
| Auto DST |
Yes |
| Recording Qualities |
Super / High / Standard |
| Recording Modes |
Schedule / Alarm / Motion / Emergency |
| Pre-Alarm Recording |
Up to 3 Hours / User Programmable |
| Motion Detection |
Yes (22 x 15) |
| Playback Control |
x1, x2, x4, x8, x16, x32, x64, Extreme |
| PTZ Control |
RS-485/422 Serial Port 1 |
| Preset Touring |
Yes |
| POS / ATM Support |
Up to 4 Channels Over USB (Optional) |
| Multi Language |
English / Danish / Chinese (Traditional) / Japanese / Korean / Italian / Polish / Russian / Chinese (Simplified) / Thai / Turkish / Spanish / French / Czech / German / Persian |
| Primary Storage |
SATA HDD (Up to 2+1) |
| Clip Copy Storage |
Built-in Internal DVD-RW Driver, Via USB HDD, Memory Stick |
| Dimension(WxHxD) |
350 mm x 65 mm x 380 mm / 13.78 inch x 2.56 inch x 14.96 inch |
| Operating Temperature |
5`C~40`C / 41`F~104`F |
| Operating Humidity |
0% ~ 90% |
| Power Adapter |
Free Voltage 12VDC, 5A |
| Power Consumption |
Max 40W |
| Agency Approval |
FCC / CE |
